The Gigabyte GA‎-H61M‎-S2PT ‎(‎rev‎.‎ 1.0‎)‎ uses the Intel LGA 1155/Socket H2 CPU socket‎.‎
Any compatible Intel CPU will have the same socket entry‎.‎ It uses the DDR3 memory type‎,‎ with maximum speeds of up to 1333 MHz‎,‎
and 2 DDR3 slots allowing for a maximum total of 16 GB RAM‎.‎


 CPU

    Support for Intel® Core™ i7 processors/Intel® Core™ i5 processors/ Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors

    in the LGA1155 package
    L3 cache varies with CPU

‎(‎Some Intel® Core™ processors require a graphic card‎,‎ please refer ‎"‎CPU support List‎"‎ for more information‎.‎‎)‎
Chipset

    Intel® H61 Express Chipset

Memory

    2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
    * Due to a Windows 32‎-bit operating system limitation‎,‎ when more than 4 GB of physical memory is installed‎,‎ the actual memory size displayed will be less than the size of the physical memory installed‎.‎
    Dual channel memory architecture
    Support for DDR3 1333/1066/800 MHz memory modules
    Support for non‎-ECC memory modules
    Support for Extreme Memory Profile ‎(‎XMP‎)‎ memory modules
    * To support XMP memory‎,‎ you must install an Intel® 22nm ‎(‎Ivy Bridge‎)‎ CPU‎.‎

‎(‎Please refer ‎"‎Memory Support List‎"‎ for more information‎.‎‎)‎
Onboard Graphics
Integrated Graphics Processor‎:‎

    1 x D‎-Sub port

Audio

    Realtek® ALC887 codec
    High Definition Audio
    2/4/5.1/7.1‎-channel
    * To configure 7.1‎-channel audio‎,‎ you have to use an HD front panel audio module and enable the multi‎-channel audio feature through the audio driver‎.‎

LAN

    Realtek® GbE LAN chip ‎(‎10/100/1000 Mbit‎)‎

Expansion Slots

    1 x PCI Express x16 slot‎,‎ running at x16
    ‎(‎The PCI Express x16 slot conforms to PCI Express 3.0 standard‎.‎‎)‎
    * Whether PCI Express 3.0 is supported depends on CPU and graphics card compatibility‎.‎
    1 x PCI Express x1 slot
    ‎(‎The PCI Express x1 slots conform to PCI Express 2.0 standard‎.‎‎)‎
    2 x PCI slots

Storage Interface
Chipset‎:‎

    4 x SATA 3Gb/s connectors

USB
Chipset‎:‎

    8 USB 2.0/1.1 ports ‎(‎4 ports on the back panel‎,‎ 4 ports available through the internal USB headers‎)‎

Internal I/O Connectors

    1 x 24‎-pin ATX main power connector
    1 x 4‎-pin ATX 12V power connector
    4 x SATA 3Gb/s connectors
    1 x CPU fan header
    1 x system fan header
    1 x front panel header
    1 x front panel audio header
    2 x USB 2.0/1.1 headers
    1 x Clear CMOS jumper

Back Panel Connectors

    1 x PS/2 keyboard port
    1 x PS/2 mouse port
    1 x D‎-Sub port
    1 x parallel port
    1 x serial port
    4 x USB 2.0/1.1 headers
    1 x RJ‎-45 port
    3 x audio jacks ‎(‎Line In‎,‎ Line Out‎,‎ Mic In‎)‎
